ATRILES POR SEPARADO
CARACTERISTICAS
| Trigger Interface |
- 3-Zone: Snare, Crash 1/2*, Ride
- 2-Zone: Tom 1/2/3/4, HH, Crash 3
- 1-Zone: Kick
Crash 1/2 support 3-zone with using Tom 4/Crash 3 cables.
EFNOTE 5 uses the Crash 3 cable for the splash cymbal.
|
| Audio / MIDI Interface |
- Line (1/2) Output: 2x TS Phone (+4dBu, Unbalanced)
- Phones (3/4) Output: Stereo Mini-Phone (320 mW + 320 mW @32Ω)
- Audio Input: Stereo Mini-Phone (+2dBu Max)
- USB Audio: 8-ch Output / 2-ch Input (Mac/Windows ASIO)
- USB MIDI In/Out
- Bluetooth Audio Input
- Bluetooth MIDI In/Out
- MIDI Out: 5-pin DIN
|
| Drum Kits / Instruments |
- Preset Drum Kits: 17 (Editable)
- User Drum Kits: 83
- Instruments: Acoustic Drums/Cymbals (Stereo), Percussion (Stereo), Attack Elements
- User Inst Library: 128 (Can be stored customized instruments)
|
| Edit Parameters |
- Level, Pan, Tuning, Muffling (for each pad)
- 2-Band EQ (for each pad)
- Ambience Effect (8 Types)
- Pad Layer
|
| Dimensions |
- 172 (W) x 106 (D) x 47 (H) mm
- 700 g
Excluding protrusions
|
| Power |
- DC 12 V, 500 mA (Nominal) / 800 mA (Max)
|
Hardware
| Titular de tom |
|
- 1x brazo porta toms
- Inclinador de barra en L con engranajes
- Varilla moleteada de acero al carbono
- Diámetro de la varilla en L: φ11,5 mm (7/16")
- Diámetro del tubo: φ22,2 mm (7/8")
- Rango de ajuste de altura: 700 -- 900 mm
|
| Brazo de platillo Splash |
|
- 1x varilla Z corta
- 1x varilla Z larga
|
| Brazo del módulo de sonido |
|
- 1x brazo de módulo de sonido
- 1x bandeja para teléfono inteligente
|
